Description
Proel S18A Active Subwoofer 18″ 600 Watt
PROEL introduces the S Series, a new range of compact and powerful sub-woofers designed to complement PROEL full-range speakers. The variety of size, power and SPL offered by the four active S models provides, at an unbeatable price point, the perfect low extension solution for any speaker model available in the PROEL range.
All the S models feature high-excursion woofers in a Hybrid Band Pass configuration (HBP). This innovative design provides a higher efficiency compared to direct radiation sub-woofers and, in addition, guarantees a much better coupling of the tuning ducts with the external air, reducing the distortion and the air turbulence, for a more defined sound and deep and punchy lows.
The new CLASS D amplifier modules with SMPS (Switch Mode Power Supply) can generate a massive amount of continuous power in a compact, lightweight and reliable package. All the modules include a STEREO pre-amp section, 24dB/oct. crossover filters with selectable frequency and PHASE reverse switch.
The cabinets are built with 15/18mm plywood and finished with extra-durable polyurethane paint. They feature two flush handles and four sturdy 75mm wheels for an easy transport (S15 and S18 only).
- Compact active HBP sub-woofer
- 18” woofer with 4” VC for a deep and extended response
- 1200 W peak power
- STEREO input, link and output
- SPL MAX 131 dB
- Frequency response 36 Hz – 140 Hz
System type: 2-way vented enclosure
High Frequency Device: 1” compression driver with 1″ VC
Low Frequency Device: 10” woofer with 2” voice coil
Angular Coverage: 90° H x 60° V
Total peak power: 600 W
HF Amplifier Continuous Power: 50 W Class AB
LF Amplifier Continuous Power: 250 W Class D
Power Supply: SMPS
Processing: Analog
Frequency Response: 60 Hz – 20 kHz
Max SPL: 123
Connectors: IN: COMBO, LINK: XLR M
Controls: LEVEL, LINE/MIC selector, LOW EQ, HIGH EQ, GND LIFT, FRONT LED selector
Flying System: 4 x M10 top/bottom
Construction: Plywood
Cabinet Colour: Black
Handles: 1 x rear
Mounting Pole: 1 x bottom, dual angle
Power Supply: 230 or 120 VAC 50/60 Hz with LINE VOLTAGE selector
Dimensions (W x H x D): 340 x 515 x 310 mm
Weight: 12.5 kg / 27.6 lbs.
